50Hz Gasoline Engine Automotive Education Equipment Engine Control System Customized

Brand Name : ZHONGCAI

Model Number : ZC-QCA15A

MOQ : 1

Payment Terms : T/T

Delivery Time : 15-25Work Days

Transmission : Manual

product name : Automotive Education Equipment

Steel Pipe : 60X40X3mm

feature : Interactive Training Module

Certification : IS09001 and CE

Language : Customized

type : Gasoline Engine Trainer

Frequency : 50Hz

Suitable For : Automotive Technology Training Programs

Power Supply : 220V/50Hz

Function : Operation Maintenance and Troubleshooting

Cylinder Number : 4 Cylinders

Contact Now

Gasoline Engine Automotive Education Equipment Engine Control System Training Board
Training Objectives
Master Santana 3000 specific sensor/actuator signal measurement techniques
Develop troubleshooting skills using automotive fault diagnosis training equipment
Practice diagnostic tool operations (code reading/clearing/data analysis)
Understand electronic control principles through hands-on operation
Product Introduction
This automotive training equipment is designed as an engine cutaway model mounted on a heavy-duty rotation stand, allowing 360-degree maneuverability for hands-on automotive education. Ideal for automotive teaching aids, it helps students master engine disassembly and reassembly techniques.
Key Features & Specifications
Feature Description
Functional EC System This system accurately simulates the complete electronic engine management of a Santana 3000, replicating real-world operations of the ECU, sensors, and actuators for a comprehensive learning and diagnostic experience.
Visual Observation Four 120ml transparent glass cylinders are integrated, allowing for direct visual monitoring of the fuel injection process, which aids in understanding injector performance and spray patterns.
Interactive Panel Constructed from durable 4mm aluminum, the panel features a full-color, detailed circuit diagram. It is equipped with numerous test terminals for hands-on signal measurement and circuit analysis.
Real-time Monitoring The system is fitted with four digital voltmeters and a set of standard engine gauges, providing immediate visualization of critical parameters such as RPM, voltage, and sensor readings during operation.
Fault Simulation Includes a remote-control unit (with a 10-meter operating range) to activate or deactivate a variety of system faults. This feature is essential for safe and effective practice in troubleshooting and diagnostic procedures.
Diagnostic Capability A standard OBD-II diagnostic port is accessible, enabling users to connect professional scan tools to read and clear diagnostic trouble codes (DTCs), bridging the gap between the trainer and real-world repair scenarios.
Power Supply The unit features an integrated power converter, transforming standard AC 220V input to the required stable DC 12V, eliminating the need for an external battery and ensuring convenient setup and operation.
Dimensions The trainer has a compact footprint with overall dimensions of 1600mm (length) * 600mm (width) * 1700mm (height), making it suitable for various workshop or classroom environments.
As a professional automotive training equipment manufacturer, we provide this Santana 3000 specific training system with complete teaching resources. The automotive training board combines the benefits of automotive training simulators and practical automotive teaching aids for effective skill development in gasoline engine electronic systems.
